Saw all structural shapes, including right and left miters
(동영상이 끊길 경우, 잠시 일시정지를 눌러 주시기 바랍니다)
The Patented Design of the Peddinghaus 1270 Miter Series Saw delivers high speed sawing to all structural shapes and profiles up to 30 degrees right and left miters. The robust design provides fast sawing times, accurate miter cutting, and minimal scrap with a unique “pivot from above” frame. The 1270 Miter Series Saw is the proven productivity leader in the industry, ideally suited for high tonnage and productive work shops – the perfect companion to the Peddinghaus BDL 1250 drill line.
The Peddinghaus DGP 1270 is the only miter band saw – carrying international patents - that miters up to 60 degrees right and left with a unique pivot and clamping design that virtually eliminates scrap. Users report up to a 25% productivity increase in shop throughput with the DGP 1270 employing Peddinghaus Speed Sawing technologies.
Above Pivot Design
Peddinghaus has closely worked to develop the only above Pivot Design on Structural Bandsaws.
Just what does this exceptional design do for you?
Totally eliminate chips and coolant from wearing on your miter gearing
Just how big is this Pivot Gear?
The gear measures 32" wide x 2 ¼" high / 813mm x 57mm.
Hydraulic Moving Vise Clamp
Depending on the required mitre angle, as well as the sawing task, it is possible to position the hydraulic material vise at either the infeed or outfeed side of the sawblade, this ensures a minimum amount of material is needed for trim cuts and tail end cuts and the material is always clamped square at 90° and as close as possible to the saw blade.
Structural Steel Mitering Applications
The patented DGP 1270 is proving to be the most popular band saw for the structural steel mitering applications.
Structural Mitering Requirements
The DGP 1270 miters to plus or minus 60 Degrees, which meets all structural mitering requirements – including compound miters.
DGP 1270 with Accumeasure
The DGP 1270 is pictured with the Peddinghaus Accumeasure Saw Measuring system. This productive system features the patented Peddinghaus Roller Feed Measuring system in perfect synchronization with a Siemens 840 CNC Control for superior accuracy. The Accumeasure also features a Signoscript CNC carbide marking system for easy identification of all sawed sections.
The Patented Design of the Peddinghaus 1270 Miter Series Saw delivers high speed sawing to all structural shapes and profiles up to 30 degrees right and left miters. The robust design provides fast sawing times, accurate miter cutting, and minimal scrap with a unique “pivot from above” frame. The 1270 Miter Series Saw is the proven productivity leader in the industry, ideally suited for high tonnage and productive work shops – the perfect companion to the Peddinghaus BDL 1250 drill line.
